Panels for front access or front/rear
access construction
Protection class IP 41 to IP 54
Ambient temperature rating 50° C
Factory built to client's specifications
TECHNICAL DATA
INCOMER
ACB, 3-pole or 4-pole, 1600 to 3200A, 65 to 85kA, fixed or drawout pattern, manual or motor operate
BUS COUPLER
ACB as above
Electrical and/or mechanical interlocking between incomers and bus coupler can be provided, as well as various protection, tripping and indicating functions.
OUTGOINGS
ACBs as above
MCCBs, 3-pole or 4-pole, up to 1250A, 36 to 65kA.
BUS BARS
H.C.H.D. copper, electrolytically tinned and colour coded
ENCLOSURE
Electrogalvanized sheet steel 2 mm, polyester powder coated to RAL 7032 textured, with removable rear covers, extendable on either side.
CABLING
Removable gland plates on top and bottom, non-ferrous type for single core cables, punched to client's requirements.
Termination for up to 4 cables per phase can be provided
